FOTON Diesel 4WD ICU Box Type Ambulance

I. Vehicle Specification:

Make:                             FOTON Motors

Model Code:                  BJ2037Y3KDV-AA

Model Year:                    2020

Body Type:                     Box

Transmission:                MT 5-speed mechanical type

Displacement:                2776ml

Safety:                            ABS+EBD,Airbag for driver

Fuel Type:                      Diesel

Overall Dimension:       5445×1830×2600mm

Wheelbase:                    3105mm

Gross Vehicle Weight:  2910kg

Tire Size:                        245/70R16

Fuel Tank:                      65L

Steering:                        Left Hand Drive/ Right Hand Drive

II.Ambulance Conversion Specifications:

Emergency Alarm System

1. 100W LED alarm light bar, red/blue color

2. Blue Flashing LED alarm lights mounted on left and right and rear side of vehicle

Power Supply and Lighting System

1. LED illumination lights in the roof of patient's compartment

2. Spotlight lights

3. LED illumination lights in both sides and rear side

4. Electric ventilation fan

5. Ultraviolet Disinfection Lamp

6. 1500W inverter

7. 100Ah backup battery, Including dual battery isolator

8. Outside outlet: 220V

9. 15m mobile cable

10. AC 220V outlets in patient's compartment

11. DC 12V outlets in patient's compartment

12. AC 220V power socket in driver’s cab

13. Multi-function control panel

14. Interphone

Patient's compartment

1. Rear air conditioning:  Independent Control

2. Rear heating system:  Independent Control

3. Anti-collision headrest: middle door / rear door

4. Wear resistant non-slip blue medical floor: The floor of the medical cabin is made of acid-resistant, alkali-resistant, fireproof, anti-skid and anti-static floor leather

5. PVC board combined medical cabinet: Oxygen tank cabinet, medical cabinet, equipment storage cabinet and etc.

6. Handrail installed on middle door and rear door

7. Handrail installed on the roof of vehicle

8. Transfusion hanging bracket mounted in the roof of Patient's compartment

9. Fire extinguisher

10. Stainless steel dirt tub

11. Cabinet bench (suitable for 2 people) with safe belts, handrail and blue leather

12. Folding seat with safe belt installed on partition wall

13. 10L oxygen bottle with bracket

14. Oxygen supply system: Medical cabin built-in oxygen piping system, oxygen pressure reducing valve

15. Oxygen outlet

16. Oxygen humidifier

17. Ventilator changeover connector

18. Automatic self-lifting stretcher mounted to patient's compartment

19. Adult spine board

20. Child spine board

21. Strong blue or red reflective strip in waist of body

III.Optional Medical Equipment:

1. First Aid Bag

made of corduroy waterproof fabric, lightweight, heavy duty,

resistant and washable , extra visibility with reflector strips on the sides. Spacious to fit other needed items such as medications, etc.

2.Patient Monitor

A.True and professional pacemaker acquisition channel, 50k sample rate, recording of pacemaking impulse, assistant diagnosis of pacemaker working performance.

B.One size AAA battery can record more than 48 hours continuously.

C.The standard configuration is 4G storage capacity, supporting 32G.

D.File record formats can be copied directly.

E.Multilanguage switchover.

3.Aluminum Alloy Foldaway Stretcher

This stretcher with wheels, outriggers and can be folded. It is made of high strength aluminum alloy and the water-tightness leather material. The back of this stretcher can be lifted, and the maximum angle is 60°. It is characterized by its being fashionable structure, light-weighted, easy-carried, use-safely, reliable quality and easy for sterilization. It is commonly used in hospital, gymnasium, ambulance, army hospital to carry the patients and the wounded.

Warm prompt: more equipment could be optional, please contact our sales manager to get more information.
