M105C Cummins Engine 105 Tons Mining Dump Truck
Highlight Front hydro-pneumatic suspension Welded rigid frame M90 & M90A applies Eaton full hydraulic steering 25 tons front axle + 35 tons middle and rear axle M90 & M90A applies Cummins 480hp engine or Weichai 480hp engine Fast 7DS220 manual transmission or Allison 4800 optional Hyva...
| Model | M105C-447M | M105C-447A | M105C-447M | M105C-447A | |
| Size | Overaldimension(mm) | 9600×3680×4300 | |||
| Wheel base(mm) | 4000+1690 | ||||
| Inner dimension of box(mm) | 6400×3400×1750 | ||||
| Weight | Body capacity(m³) | 38-40 | |||
| Curb Weight(kg) | 35000 | ||||
| Rated load(kg) | 70000 | ||||
| Rated total weight(kg) | 105000 | ||||
| Performance | Engine | M15PIusCSIV 447kW | |||
| Transmission | FAST 8DSS330 | Allison 4800ORS | FAST 8DSS330 | Allison 4800ORS | |
| Steering Engine | Eaton full hydraulic | ||||
| Front axle | M25T front axle | ||||
| Rear axle | M40T casting dual reduction tandem axle | ||||
| Frame | 480×140 Welded rigid frame | ||||
| Body description | High strength plate, bottom 16mm, side 12mm, front hoisting, Hyva hoisting system, square box | ||||
| Leaf spring | Front: pneumatic hydraulic / Rear: 120×27×18 | ||||
| Min ground clearance (mm) | 435 | ||||
| Min turning radius (m) | ≤12 | ||||
| Max gradeability (%) | 35 | ||||
| Tire | Specification | 16.00R25 | |||
