6x6 SCR 13L Engine 70 Tons Dump Truck

Model			O66-3670-S460MO12	O66-3670-S480MO12
Drive			6×6
GVW/GCW (kg)			36000/70000
Main configuration	Cab	Type	C-Rest
		Suspension	Front fixed rear hydraulic suspension
		Air conditioner	Electric air conditioning
	Engine	Model	ISZ460-51	ISZ480-51
		Emmission Standard	Euro II - EuroV
		Rated Power (hp)	460	480
	Transmission	Model	12JSDX240TA
		1ST/Top Ratio	12.098/0.779
	Transfer Case	Model	TC3200-VI
		High/Low Ratio	0.95/1.583
	Axle	Steering axle	9000
		Drive axle	27000
		None	0
		Ratio	4.769
	Chassis	Frame (mm)	300×90×(8+8+6)
		Wheel base (mm)	3800+1450/4000+1450/4200+1450/4400+1450/4600+1450
		Fuel tank	FT350S
		Tire	295/80R22.5 18PR - LC3750
		Supension	Front and rear multi-leaf spring
	Container space (mm)		5500-8600
Applicable condition	Applicable condition		Non-road and special transport
	Economic/Max. speed (km/h)		59-70/110	#N/A
Basic equipment			Electric window lifter, metal bumper, two-stage pedal, water tank protection grille
Options			Deflectors, air main seat electric flip, Front and rear spring suspension
